ProjectElectrical design software

Proteus PCB Design

Sheet
A-22 of 34
Drawn by
—
From
Not published
Free plan
No
Runs on
Windows
Rev.
6.8
Visit site Alternatives

Summary

Proteus PCB Design is ranked #22 of 34 in electrical design software on Bettesworth Construction. It runs on Windows. There is no free plan. A free trial is offered.

Proteus PCB Design plans and pricing

All plans
Proteus Design Suite (commercial packages) Not published Single-user prices are listed in GBP; multi-user pricing by contact · Configurable PCB, simulation and IoT modules · Six months of Update Service Contract included labcenter.com · 5 Oct 2026

Compared on electrical design software

Free plan
Nolabcenter.com
Schematic capture
Yeslabcenter.com
Electrical simulation
basiclabcenter.com
Standards libraries
Yeslabcenter.com
MCAD integration
Yeslabcenter.com
Deployment
desktoplabcenter.com

Facts

Purpose
Proteus combines schematic capture and PCB layout for designing, testing and laying out printed circuit boards.labcenter.com · 5 Oct 2026
PCB design
PCB tools include design-rule management, power planes, shape-based autorouting and manual push-and-shove routing.labcenter.com · 5 Oct 2026
High-speed design
Professional PCB features include differential-pair routing and length matching; differential pairs require PCB Design Level 2 or higher.labcenter.com · 5 Oct 2026
HDI
Proteus 9.2 adds HDI micro-via support with 1+n+1 board construction in the Stackup Wizard.labcenter.com · 5 Oct 2026
Manufacturing output
Proteus supports Gerber X2, traditional RS274X Gerber/Excellon, IPC-D-356 netlists and ODB++ output.labcenter.com · 5 Oct 2026
Parts libraries
The product includes over 10,000 supplied library parts and integrated web search for access to over 15 million parts from SamacSys and SnapEDA.labcenter.com · 5 Oct 2026
Other library imports
The library importer supports parts from vendors including Ultra-Librarian and PCB Library Expert.labcenter.com · 5 Oct 2026
Integrations
Proteus 9.2 adds STM32CubeIDE integration via GDB and expanded simulation for BLE and RFID.labcenter.com · 5 Oct 2026
Trial limits
The demo has no time limit for PCB layout, limits microcontroller simulation to 14 days, and does not allow saving work or simulating custom microcontroller designs.labcenter.com · 5 Oct 2026
Platform requirement
The FAQ lists Microsoft Windows 10 as the minimum operating system and says ARM processors such as Snapdragon are unsupported.labcenter.com · 5 Oct 2026
Security
Labcenter says its website uses SSL/TLS and that card details are handled by an external PCI DSS compliant payment provider and are not stored or seen by Labcenter.labcenter.com · 5 Oct 2026
Support
Direct technical support is free for professional users, with email support preferred for project issues and a typical email response time of one to two working days.labcenter.com · 5 Oct 2026
Intended users
Labcenter describes Proteus as used in industry for professional PCB design and rapid prototyping, and in education for teaching electronics, embedded design and PCB layout.labcenter.com · 5 Oct 2026

Company

Founded
1988labcenter.com · 28 Sept 2026
Headquarters
Skipton, North Yorkshire, Englandlabcenter.com · 28 Sept 2026
